AT-S201
Voice Messaging
Sharing live video with multi-users simutanousely
Ultra-Smooth 355° Pan and 110° Tilt Control with APP
Works as a video recorder even without network connections
Megapixel HD Video Outstanding Clarity & Color Performance
The optimal combination of image sensor and processor together with the optimizationof image processing algorithms & H.264/AVC video coding enables the camera to deliver
a smoother video streaming at lower bitrates, a superior image quality with outstanding
clarity & color performance.
◆ 3 Megapixel Optical Lens; F/2.0 Aperture
◆ HD Sensor & Image Signal Processor
◆ Proprietary Image Processing Algorithm Optimization
◆ Proprietary H.264/AVC Video Coding Optimization
IR Night Vision for low light conditions
10 built-in high power SMD850 IR LEDs allow the camera to produce a higher concentrationof light & higher intensity infrared radiation which in term increases the lumens so that for
the camera to deliver a sharp & clear image in low light or nighttime conditions, even in
complete darkness.
Voice Messaging
The camera not only enables two-way audio communication, but also enables you to send
voice messages.
Works as a video recorder even without network connections
Even in the case of a network failure or no network connections available at all, as long as
the power is turned on, the camera can work as a video recorder so that you can keep your
cherish memories .
Seamless Loop Recording
Play back whenever you`d like so that you don`t miss anything
◆ Can record locally to a MicroSD card so that you will have full control over your recordings.
◆ Supports up to 64GB MicroSD card (not included) allowing you upto 20 days circular recording.
◆ Uninterrupted audio & video recording even in the event of network connection failure.
Sharing live video with multi-users simutanousely
Our free apps allow you to share live stream with your family & friends.
Showing your loved ones that you care being there even when you are not
Remote Viewing on Computer, Smartphone or Tablet
See, hear & communicate using your Computer, Smartphone or Tablet
with free apps (QQ or Danale ) enhancing a better peace of mind.
Ultra-Smooth 355° Pan and 110° Tilt Control with APP
Ultra-smooth 355° pan and 110° tilt capability allows you to keep an eye on a larger area
by viewing live stream or taking snapshots.
Motion-driven alerts sent to your mobile device
The camera is also able to capture clips and can send you alerts whenever any motions
are detected so you will always know what`s happening at home.
Two-Way Talk
With the utilization of high efficiency audio format AAC which is a noise cancelling algorithm, the
built-in speaker & mic enable everything you say or hear to come through clearly and instantly.
It`s almost as handy as a video phone.
Simple Installation
Desktop / Wall Mount / Roof-Top Mount whichever way you like
■ Applications
Home & Family: Keep an eye on small children or elderly parents even whenyou are away or on the go.
Storefront & Small Offices: Monitor the security and assets of your business
remotely when you can`t be present all the time.
Education: Keep an eye out on children `s activities in daycare centers or
kindergarten watching their goings on.
For more features, more details please check out the specifications for your reference.
|
Name |
Smart Wi-Fi Camera |
|
|
Type |
AT-S201 |
|
|
Spec. |
100W 1/4 CMOS Smart WI-FI Camera |
|
|
Camera |
Sensor |
SC1045 |
|
Processor |
AK3918E |
|
|
Resolution |
1280*720 |
|
|
Mini Illuminance |
0.0001lux（IR ON） |
|
|
Lens |
3.6mm |
|
|
Day-Night |
IR-Cut |
|
|
Video |
Video Coding |
H.264 |
|
Video Play |
Support Multi-Viewer |
|
|
Audio Coding |
G.711A |
|
|
Audio Output |
Inter-Speaker |
|
|
Audio Input |
Inter-Microphone |
|
|
Fuction |
Recording |
Auto Record/Cycle Record |
|
Capture |
Support |
|
|
Memory |
Micro SD/PC |
|
|
App Protocol |
QQ SmartLink |
|
|
Intercom |
Support |
|
|
Motion Detection |
Support |
|
|
Interface |
WiFi |
Support,802.11 b/g/n |
|
Power |
DC3.5*1.35 |
|
|
Reset |
Key Reset |
|
|
Micro SD |
Support |
|
|
Other |
LED |
Status LED |
|
Power |
DC 5V/2A |
|
|
Consumption |
1.5W(IR ON-3W) |
|
|
Action Temperature |
-10℃～55℃ |
|
|
Action Humidity |
10%～90% |
|
|
Size |
135mm×115mm×160mm |
|
|
Weight |
≈300g（camera only） |
|
